Some Common Sense Of Bubble Bag Machine

Mar 2024-03-18

The bubble film machine is a reliable packaging and filling solution designed to withstand high pressure, protect against moisture and shocks. It is commonly used for packaging electronic instruments, household appliances, handicrafts, glass products, bicycles, and more. However, certain production batches faced issues with the outer packaging, rendering it unusable. Let's explore the possible reasons behind this.

There could be several factors contributing to the problems encountered in the outer packaging during production. One possible reason could be a malfunction or misconfiguration of the bubble film machine itself. If the machine is not calibrated correctly or experiences technical issues, it may lead to inadequate packaging quality.

Another factor to consider is the selection of improper packaging materials. The bubble film used may not be suitable for the specific products being packaged, or it may not meet the required industry standards. Insufficient cushioning, poor seal strength, or low tear resistance of the bubble film may contribute to the packaging failures.

Additionally, human error could play a role in the issues faced during production. Improper operating procedures, lack of training, or negligence in quality control could result in defective packaging. It is crucial for operators to follow established guidelines and ensure proper settings, maintenance, and inspection of the equipment to avoid such problems.

To address these challenges, it is essential to conduct thorough quality checks throughout the production process. This includes inspecting the bubble film machine regularly for any technical issues, using high-quality and suitable bubble film materials, and providing proper training to operators to ensure they adhere to the correct procedures.

By identifying and rectifying the underlying causes, the bubble film machine can reliably deliver its intended purpose of providing pressure-resistant, moisture-proof, and shock-proof packaging for a wide range of products.

If you're experiencing poor transparency in the film blown by your bubble film machine (air cushion film machine), it may be due to a low extrusion temperature and poor resin plasticization. To fix this issue, try increasing the extrusion temperature to promote more even resin plasticization. This should lead to improved transparency and overall film quality.

One common problem with bubble film machines (air cushion film machines) is the inflation ratio being too large, resulting in unstable bubbles that swing back and forth and are prone to warping. To solve this issue, it is important to adjust the inflation ratio appropriately and reduce it as needed. Taking these steps can help ensure that your bubble film machine produces consistent and reliable results.

To achieve uniform thickness of the film, it is crucial to adjust the cooling device and ensure that the air volume from the air outlet is consistent. In cases where the airflow around the cooling air ring varies, it becomes necessary to make adjustments in order to maintain the desired cooling effect. It is important to remember that uniform air volume plays a vital role in achieving a uniform film thickness. Therefore, careful attention must be given to the cooling device and its settings to ensure optimal results.


The main components of a bubble film machine, also known as an air cushion film machine, consist of five parts. These are the extruder, electric control cabinet, forming machine, tractor, and coiler. Together, these parts work seamlessly to create high-quality bubble film products that can be used for a variety of purposes. The extruder is responsible for melting and shaping the plastic material into the desired bubble film shape, while the electric control cabinet ensures that the machine runs smoothly and efficiently. The forming machine then takes the shaped plastic material and forms it into the bubble film, which is then pulled through the tractor. Finally, the coiler winds the finished product onto a roll for easy storage and transport. With these five components working in harmony, bubble film machines are a valuable addition to any manufacturing operation.

The main components of the extruder include a motor, a reducer, a screw, a barrel, a screen changer, a die, and a heater. Its primary function is to melt, filter and extrude raw materials efficiently.

The essential components of the forming machine are the forming rollers and the vacuum pump. Depending on customer specifications, the forming rollers come in three different sizes: 6mm, 10mm, and 28mm. The primary function of the forming machine is to efficiently shape the molten raw material, which is extruded from the mold, into an air cushion film product. This process plays a crucial role in the overall production.

The main components of the traction machine are the traction roller, slitting device, and film guide roller. Its primary function is to efficiently extract the air cushion film from the forming roller.

The coiler component of the air cushion film production line consists of a frequency converter, two film rolls, and a torque motor table. Its primary function is to efficiently wrap up the air cushion film as it comes out from the tractor and turn it into a roll that can be easily packed and stored in the warehouse. The coiler is an essential part of the production process and ensures that the air cushion film products are properly packaged and stored for future use or distribution.

The bubble film machine (air cushion film machine) relies on its electrical control cabinet to ensure smooth operation. This cabinet consists of various crucial components such as a thermostat, electrical materials, and a frequency converter. Together, they form the central electrical control system of the equipment. The overall quality of the bubble film machine greatly depends on the quality of these components. Hence, it is vital to thoroughly inspect the electrical control cabinet when purchasing such machinery. By carefully examining the components, one can ensure the efficiency and reliability of the bubble film machine.
